Wax Injection Machine Suppliers by Jar Hing
Product details of the wax injection machine suppliers
Product Information
With its appealing design, Jar Hing wax injection machine suppliers will attract more attention than before. The product meets the highest level of quality and safety. Quality check is fundamental to the production of wax injection machine suppliers.
|
Model No. |
MYY25-2M-ZN-HS-Z |
|
Place Of Origin |
China |
|
Old And New |
New |
|
Video Factory Inspection |
Provided |
|
Mechanical Test Report |
Not Available |
|
Marketing Type |
Ordinary Product |
|
Core Component Warranty Period |
1 Year |
|
Core Components |
Plc, Motor, Pump |
|
Warranty Period |
1 Year |
|
Core Selling Point |
High Productivity |
|
Out-of-warranty Service |
Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
|
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets) |
None |
|
Showroom Location (in Which Countries Are There Sample Rooms Overseas) |
None |
|
Applicable Industry |
Other |
1. two station 25t clamping pressure;
2. the maximum mold opening height is 600mm;
3. the minimum clamping height is 75mm;
4. dimension of pressing plate and lower workbench 770 × 600mm;
5. die space 620 × six hundred × 600mm;
6. the maximum single wax injection volume is 5L;
7. temperature parameters include: upper section temperature of cooling barrel, lower section temperature of cooling barrel, wax discharge temperature of cooling barrel, preparation temperature, preparation wax discharge temperature and wax injection temperature.
8. multi stage wax injection mode, wax injection pressure 0 ~ 10MPa;
9. all oil cylinders, wax injection cylinders and wax replenishment cylinders shall adopt Japanese NOK sealing rings;
10. digital control is adopted for fast and slow mode closing and injection pressure and injection flow.
11. it has the linkage function of manipulator mold taking.
12. all processed parts of the pressing plate, worktable and nozzle advance and retreat lifting parts of the Wax Injection Machine shall be chrome plated.
13. the temperature control adopts the independent heating and cooling type of insulation barrel, which avoids the previous equipment valve cracking and the carbon deposition of heat transfer oil.
14. the hydraulic oil tank is made of stainless steel; The hydraulic oil is directly cooled by thick wall copper pipe, which avoids the potential safety hazard of hydraulic oil cooler freezing and water inflow in the past;
15. the servo oil pressure pump has the advantages of low energy consumption, low oil temperature and low noise.
16. with safety light curtain, with anti pressure hand protection function.
17. it can store 200 sets of process parameters, and all process parameters required for operation are set on the touch screen.
18. the paste making method adopts American MPI bucket + Fuhao secondary cooling paste making system, which is suitable for the production of thick wall wax parts.
19. have system fault diagnosis and alarm functions.
Company Feature
• Established in Jar Hing Products has a development history of years. We accumulate rich professional know-how and experience in the machinery production.
• Jar Hing Products is located in the area of convenient traffic, with a great number of shopping facilities. This makes a convenient condition for transportation.
• Jar Hing Products's mechanical equipment has reasonable design, compact structure and stable performance. Besides, our product is easy and convenient to be operated and installed.
• Our company adheres to the customer-oriented service concept. We always provide customers with efficient, professional and high-quality custom services from the perspective of customers.
• Our company has an experienced team of professional and technical personnel to provide technical support for the production and research and development of products.
Jar Hing Products continuously supplies Wax Injection Machine,Shell Moulding Machine,De-waxing and Wax Treatment Machine,Melting and Calcining Equipment,Post-processing Equipment,Low-temperature Wax Equipment,Auxiliary Equipment of various functions and specifications. Our tents are of good quality and affordable price. We welcome orders from customers.
